Unlimited creative freedom and maximum entrance of light — a versatile stick curtain wall façade and roof system offering incredible building speed and exceptional performance, fabricated and installed in-house.
📄 Download ConceptWall 50 brochure (PDF)
The most versatile stick façade and roof system in the Reynaers range, engineered for ambitious large-scale commercial and residential projects.
Highly insulated variants achieve Uf values as low as 0.56 W/m²K, with air tightness rated AE1950 and water tightness rated RE1950.
Supports glass loads up to 700kg with wind load resistance up to 2400Pa (3600Pa CWCT safety rating) — suited to tall, multi-storey façades.
RC2/RC3 burglar resistance and Rw(C;Ctr) 47(-2;-6) dB sound reduction, with inclined, roof, clip-on cover cap and solar shading options.
Every specification refined to deliver optimal performance, versatility and production efficiency.
Independently tested and certified to exceed UK Building Regulations and industry standards.
| Performance metric | Rating / value | Standard |
|---|---|---|
| Thermal insulation (Uf) | 0.56 W/m²K | Frame U-value |
| Air tightness | AE1950 (1950Pa) | BS EN 12152 |
| Water tightness | RE1950 (1950Pa) | BS EN 12154 |
| Wind load resistance | 2400 Pa | BS EN 13116 |
| CWCT air leakage | A4 (600Pa) | CWCT Sequence B |
| CWCT water penetration | R7 (600Pa) | CWCT Sequence B |
| CWCT wind resistance (serviceability) | 2400 Pa | CWCT Sequence B |
| CWCT wind resistance (safety) | 3600 Pa | CWCT Sequence B |
| Acoustic performance | Rw(C;Ctr) 47(-2;-6) dB | BS EN ISO 717-1 |
| Burglar resistance | RC2, RC3 | Enhanced security |
| Max glass weight | 700kg | Per panel |
| Min visible sightline | 50mm | Interior & exterior view |
Ultra-slim 35mm stick curtain wall system with Passive House certified thermal performance.
Speak to our team for a free, no-obligation quote — Romsey, Southampton, Winchester & across Hampshire.
Call 01794 721 100
